1/1 Gas Detectors Alpa EcoDet XT Product code: PW-098-LPG The Alpa EcoDet XT Gas Detector is an advanced and versatile device designed for detection of LPG (C3H8, C4H10) concentration in public access facilities, such as boiler houses, industrial shops and underground car parks. See full description Functionalities: Certificates: Product description Technical details Supported gases The Alpa EcoDet XT Gas Detector is an advanced and versatile device designed for detection of LPG (C3H8, C4H10) concentration in public access facilities, such as boiler houses, industrial shops and underground car parks. Presence of the hazardous gas is revealed by means of a catalytic sensor, which guarantees reliable operation of the device without false alarms and, in consequence, smooth operation of the gas detection system deployed on the monitored facilities. The detectors are immune to humidity, variations of ambient temperature and presence of other gases. he device measures concentration of methane within established time intervals and information about exceeding of permissible thresholds it provided to the system operator when the LED indicator provided on the side part of the device is on. Such a solutions enables reliable identification of the detector status from the distance even up to several meters. The communication between the detector and the master Control Unit is provided by the 4..20 mA output signal. The Alpa EcoDet XT Gas Detector is not designed for installation in areas with potentially explosive atmospheres. Power voltageVCC 10 – 42 V ICC 130 mA Environment Ambient temperatures -20 – +50 °C 0 – +50 °C ( storage ) Humidity 10 – 90% long term 20 – 80% long term ( storage ) 0 – 99% short term Pressure 1013 ± 10% hPa Detected substance LPG (C3H8, C4H10) Measuring range 0 – 50% LEL Standard configurationwarning 1 10% LEL warning 2 15% LEL alarm 20% LEL IP 43 Analogue input parametersRIN 200 Ω Analogue input parametersRLOAD_MAX 200 Ω The output signal according to the operating status of the detectorFailure <0.1 mA Operation 4 mA Warning 1 9 mA Warning 2 11 mA Alarm 15 mA Integrated signalling equipment (optical) LED controls Protection class III Cable glands (cable diameter range) Cable glands pressed into installation pipes pipe diameter 16 mm Multi-range cable glands cable diameter 3.5 – 12 mm Acceptable cables 0.25 – 1.5 mm2 – solid wire 0.25 – 1 mm2 – stranded wire Enclosure material ABS Weight 0.3 kg Mandatory periodic inspection Every 12 months ( Validity of the calibration certificate ) Mounting 4 holes for screws with the diameters of 4 mm LPG Liquefied Petroleum Gas Placement and role in the system Files to downloadDatasheets:Alpa EcoDet XT Gas Detector - Datasheet Download fileUsers's manual:Alpa EcoDet XT Gas Detector - User Manual Download fileCE declarations:Alpa EcoDet XT Gas Detector - Declaration of Conformity Download file Related products Control Unit ModulesAlpa MOD LED1Control Unit ModulesAlpa MOD LED 8Control UnitsEcoAlpa
